HB-100WS Stationary Concrete Batching Plant with Skip Hoist

Specification Value Unit
Compacted Concrete Output 100 m3/hr
Batch Count 50 cycle/hr
Mixer Capacity (compacted) 2 m3
Mixer Capacity 3 m3
Mixer Motor Power 2x37 kW
Aggregate Compartments Qty. 4-6 Quantity
Aggregate Compartment Capacity 30-50 m3
Aggregate Weighing Conveyor 1.000x15.630 mm
Mixer Feeding Conveyor Skip Hoist -
Aggregate Weighing 4.400 kg
Cement Weighing 1.000 kg
Water Weighing 700 lt
Additives Weighing 20 kg
Cement Screw Conveyor 273x11.500 mm
Cement Silo 2-4 Quantity
Cement Silo Capacity 75-100-150-200-250 ton



Why MB-100WS Stationary Concrete Batching Plant?

  • Prompt Reply For Service And Spare Parts
  • Top Quality Components
  • Hardwearing Mixer Linings
  • Manufactured For Heavy Duty Operations
  • Optional Cladding Available
  • Reduced Power Consumption On Account Of Short
